Aluminium vacuum filters - FA Series

Aluminium vacuum filters - FA Series

This series of filters with threaded attachments is made of cast aluminium elements. All the filters come with stainless steel cartridges. Degree of filtering from 40 to 100 microns. Working temperature from 0° to 90°c.

Mounting, maintenance and cleaning

Be very careful to adhere to the flow direction, as indicated by the arrow on the filter. The filters can be mounted in any position, though we advise mounting them in the vertical position, with the tub facing downwards, thus making it easier to deposit the filtered impurities. For cleaning operations, unscrew the screws on the cover, remove the tub, and carefully wash the cartridge with diesel oil or petrol, and blow compressed air from the inside outwards; assemble everything, taking care to check that the seals are undamaged and in their correct positions. For models that do not have screws, unscrew the tub by hand, clean it as described above, then remount it by hand tightening gently.

Art. A B C
FA7-1/4 61 75 12.5 1/4" gas
FA7-3/8 61 75 12.5 3/8" gas
FA15 81 85 21 3/8" gas
FA18 81 117 21 1/2" gas
FA30 96 141 29 3/4" gas
FA35 120 175 29 1" gas
FA160 190 225 39 1 1/4" gas
FA200 190 225 39 1 1/2" gas
FA250 182 275 39 2" gas
