Multi-stage vacuum generators mod. GVML

Multi-stage vacuum generators mod. GVML

The GVML - GVLL multistage vacuum generators has an excellent ratio between flow rate and air consumption despite its compact size. It has been designed to be mounted also in a modular confi guration*, thus containing the dimensions while increasing its carrying capacity. The GVML remains an excellent choice for its simplicity and economy of use.

Available with two types of cartridges:

  • High vacuum (95%) mod. GVML
  • Low consumption mod GVLL

GVML

Mod Bar VuotoVacuumVakuum PortataVacuum flowDurchsatz ConsumoConsumptionVer-brauch
kPa Nl/min Nl/min
GVML 2 41 217.1 70.3
3 77 262.7 94.3
4 95 310.8 115.4
5 94 307.1 136.4
6 93 321.8 157.8
7 91 338.3 177.8
8 90 356.6 198.6
GVLL 2 28 194.3 48.5
3 44 244.2 61.7
4 59 284.2 76.2
5 70 308.0 90.5
6 75 323.4 104.5
7 77 334.8 117.1
8 78 345.2 128.8
